CPOINT® DMXcompander
Facts & Features:

CPOINT® DMXcompander - Run Three DMX512 Universes in one CAT-5 cable
Download the CPOINT®
DMXcompander™ Fact Sheet

DMXcompander makes it possible to run three DMX512 Universes in one CAT-5 cable.

A CAT-5 cable has four data-pairs, one pair is used as the 0V reference and the other three pairs are used for DMX512 Data+ and Data-.

Through the three RJ45 connectors on the DMXcompander, three DMX512 Universes are “COMpressed” into one CAT-5 cable through the ‘Universe 1+2+3’ RJ45 connector.

In the other end of the CAT-5 cable another DMXcompander can be used to “exPAND” the DMX512 Universes again, making them available through the three RJ45 connectors.

Together with CAT-5 cables and CPOINT’s XLRJ45 adapters, a DMX512 network can be set up very quickly and at a very low cost.

The DMXcompander can be mounted in several different ways. Below are some suggestions of how the DMXcompander can be mounted.
For more information, prices, distributor information etc, contact:
Click here...
EAN13/UPC barcode:
# 4897040870504
Product code:
DMXCOMP
MOUNTED ON A WALL
MOUNTED IN THE LIGHTING RIG

THE UNIVERSAL
UNIVERSE 3 !

NOTE: The 3rd Universe,
pin 4 and pin 5, is unspecified by the ESTA Association. It opens up the 3rd Universe to be used for something else other than DMX512, for example power.
A CAT-5 cable wire pair (24AWG x 2) is specified to carry up to 360mA at a maximum of 50V according to the TIA Association.

MOUNTED ON A DIN RAIL

Use CPOINT® XLRJ45®,
XLR to RJ45 adapters,
to connect to your
DMX512 equipment.

Use CAT-5 cables
for all wiring to XLRJ45® connectors.

The DMXcompander merges the three DMX512 Universes into one CAT-5 cable.
Link to CPOINT® XLRJ45® adapters...
Or use no adapter at all to
connect directly to DMX512
equipment with a RJ45 connector.
Need to terminate?
Link to RJ45 DMXterminator™...
Use DMXtender to extend a CAT-5 cable, or use the DMXtender as a DMX512 outlet, or inlet. Use CPOINT® XLRJ45® adapters to connect to DMX512 equipment.
Link to DMXtender™...
DMXcompander mounted with a cable-tie
DMXcompander™ Gallery
DMXcompander™ front, high resolution jpg file
DMXcompander™ back, high resolution jpg file
DMXcompander™ in a rig, high resolution jpg file
Packaging Gallery
DMXcompander™ hi-res
DMXcompander™ hi-res
DMXcompander™ hi-res
DMXcompander™ hi-res
DMXcompander™ hi-res
DMXcompander™ hi-res
Fully compliant with PLASA/ANSI E1.11-2008 (R2013) Clause 7.3 Table 4 – Connection Schedule for DMX512 Equipment Using IEC 60603-7 8-Position Modular Connectors
