EAN13/UPC barcode:
# 4897040870306
Product code:
DMXTENDER



DMXtender makes it possible to connect two CAT-5 cables together. The DMXtender can be mounted on a DIN rail, lighting rig or a wall etc.The sturdy design of the DMXtender makes it suitable for professional use.

For more information, prices, distributor information etc, contact:
Click here...

CPOINT® DMXtender
Facts & Features:

CPOINT® DMXtender - A mountable sturdy CAT-5 cable extender.
Download the CPOINT®
DMXtender™ Fact Sheet
NOTE: The 3rd Universe, pin 4 and pin 5, is unspecified by the ESTA Association. It opens up the 3rd Universe to be used for something else other than DMX512, for example power.
A CAT-5 cable wire pair (24AWG x 2) is specified to carry up to 360mA at a maximum of 50V according to the TIA Association.
MOUNTED ON A WALL
MOUNTED ON A DIN RAIL
THE UNIVERSAL
UNIVERSE 3 !
MOUNTED IN THE LIGHTING RIG
www.cpoint-lighting.com
DMXtender Gallery
DMXtender™ side view, high resolution jpg file
DMXtender™, high resolution jpg file
DMXtender™ back, high resolution jpg file
The DMXtender can be mounted in several different ways. Below are some suggestions of how the DMXtender can be mounted.
DMXtender™ front hi-res
DMXtender™ side SW hi-res
DMXtender™ side SE hi-res
DMXtender™ front hi-res
DMXtender™ side W hi-res
DMXtender™ E hi-res
DMXtender™ Back hi-res

Fully compliant with PLASA/ANSI E1.11-2008 (R2013) Clause 7.3
Table 4 – Connection Schedule for DMX512 Equipment Using IEC 60603-7 8-Position Modular Connectors
